Louisiana 5 MV 095/105/115 MT D M

////Louisiana 5 MV 095/105/115 MT D M
Refrigerated multideck cabinets Louisiana 5 MV 105 MT D 210-DLM
Multideck cabinet with infinity energy-efficient doors is for the stores of any format.
  • Connects to the remote refrigeration system
  • Dynamic cooling
  • Inner enclosure LED lighting
  • Energy-efficient fans
  • Slide-doors
Salami & Sausages Cheese Dairy products Ready-to-serve food
Confectionery Beverages
Information related to energy class (Ecodesign Regulation 2019/2024 and Energy Labelling Regulation 2019/2018) refers to specific product configurations. All configurations other than that presented in the website could require significantly different energy class information. For further details, either consult the European Product Database for Energy Labelling (EPREL) or contact our sales office.

3750

Visualizations and schemes

Refrigerated multideck cabinets Louisiana 5 MV 095 MT D 210-DLM
Louisiana 5 MV 105 MT D 210-DLM
(article: 2037.SD.XX)
Refrigerated multideck cabinets Louisiana 5 MV 095 MT D 210-DLM
Refrigerated multideck cabinets Louisiana 5 MV 095 MT D 225-DLM
Louisiana 5 MV 105 MT D 225-DLM
(article: 2037.MD.XX)
Refrigerated multideck cabinets Louisiana 5 MV 095 MT D 225-DLM
Refrigerated multideck cabinets Louisiana 5 MV 105 MT D 210-DLM
Louisiana 5 MV 105 MT D 210-DLM
(article: 2038.SD.XX)
Refrigerated multideck cabinets Louisiana 5 MV 105 MT D 210-DLM
Refrigerated multideck cabinets Louisiana 5 MV 105 MT D 225-DLM
Louisiana 5 MV 105 MT D 225-DLM
(article: 2038.MD.XX)
Refrigerated multideck cabinets Louisiana 5 MV 105 MT D 225-DLM
Regały chłodnicze Louisiana 5 MV 115 MT D 210-DLM
Louisiana 5 MV 115 MT D 210-DLM
(article: 2039.SD.XX)
Refrigerated multideck cabinets Louisiana 5 MV 115 MT D 210-DLM
Refrigerated multideck cabinets Louisiana 5 MV 115 MT D 225-DLM
Louisiana 5 MV 115 MT D 225-DLM
(article: 2039.MD.XX)
Refrigerated multideck cabinets Louisiana 5 MV 115 MT D 225-DLM

The Manufacturer reserves the right to make alterations in the specifications.

Specifications

Louisiana 5 MV 095 MT D 210-DLM
Length without sidewalls mm 937 1250 1875 2150 2500 3125 3750
Area of display part m2 2,44 3,25 4,88 5,59 6,50 8,13 9,75
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s –
Operating temperature ˚С 0…+2/+2…+4/+4…+6
Temperature class M1/M2/H1
Louisiana 5 MV 105 MT D 210-DLM
Length without sidewalls mm 937* 1250 1875 2150* 2500 3125 3750
Area of display part m2 – 4,00 6,00 – 8,00 10,00 12,00
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s –
Operating temperature ˚С 0…+2/+2…+4/+4…+6
Temperature class M1/M2/H1
Louisiana 5 MV 105 MT D 225-DLM
Length without sidewalls mm 937* 1250 1875 2150* 2500 3125* 3750
Area of display part m2 – 4,00 6,00 – 8,00 10,00 12,00
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s –
Operating temperature ˚С 0…+2/+2…+4/+4…+6
Temperature class M1/M2/H1
Louisiana 5 MV 115 MT D 210-DLM
Length without sidewalls mm 937* 1250 1875 2150* 2500 3125* 3750
Area of display part m2 – 4,75 7,13 – 10,00 – 14,25
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s –
Operating temperature ˚С 0…+2/+2…+4/+4…+6
Temperature class M1/M2/H1
Louisiana 5 MV 115 MT D 225-DLM
Length without sidewalls mm 937* 1250 1875 2150* 2500 3125* 3750
Area of display part m2 – 4,75 7,13 – 10,00 – 14,25
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s –
Operating temperature ˚С 0…+2/+2…+4/+4…+6
Temperature class M1/M2/H1

* – it requires an additional agreement (marked in red)

The Manufacturer reserves the right to make alterations in the specifications.
