Louisiana eco MSV 095/105/115 MT O M

Semi-vertical cabinets Louisiana eco MSV 095 MT O 160-DLM



Semi-vertical counters are for the stores of any format. For creating island-type zones end-face modules are available.



  • Connects to the remote refrigeration system
  • Dynamic cooling
  • Inner enclosure LED lighting
  • Energy-efficient fans
  • Shelf system of various depth
Salami & Sausages Cheese Dairy products Ready-to-serve food
Confectionery Beverages
Semi-vertical cabinets Louisiana eco MSV 095 MT O 160-DLM
Louisiana eco MSV 095 MT O 160-DLM
(article: 2015.XX)
Louisiana eco MSV 095 MT O 160-DLM
Semi-vertical cabinets Louisiana eco MSV 095 MT O 160-DLM
Louisiana eco MSV 095 MT O 200-DLM
(article: 0277.XX)
Louisiana eco MSV 095 MT O 200-DLM
Semi-vertical cabinets Louisiana eco MSV 105 MT O 160-DLM
Louisiana eco MSV 105 MT O 160-DLM
(article: 2011.XX)
Louisiana eco MSV 105 MT O 160-DLM
Louisiana eco MSV 115 MT O 200-DLM
(article: 0223.XX)
Louisiana eco MSV 115 MT O 200-DLM
Louisiana eco MSV 115 MT O 200-DLM
Louisiana eco NB MSV 115 MT O 200-DLM
(article: 0223.NBXX)
(the variant of modification which
enables the night blinds installation)
Louisiana eco NB MSV 115 MT O 200-DLM
Louisiana eco MSV 115 MT O 200-DLM

The Manufacturer reserves the right to make alterations in the specifications.

Louisiana eco MSV 095 MT O 160-DLM End-face module
Length without sidewalls mm 937 1250* 1875 2150* 2500 3750* 1875
Thickness of two sidewalls mm 60
Area of display part m2 1,5 2,0 3,1 3,5 4,1 6,1 3,1
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s ≤ 0,2
Operating temperature ˚С 0…+2 / +2…+4/ +4…+6
Temperature class М1/М2/Н1
Louisiana eco MSV 095 MT O 200-DLM End-face module*
Length without sidewalls mm 937* 1250* 1875 2500 3750* 2160*
Thickness of two sidewalls mm 90
Area of display part m2 2,3 2,9 4,4 5,9 8,9
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s ≤ 0,2
Operating temperature ˚С 0…+2 / +2…+4/ +4…+6
Temperature class М1/М2/Н1
Louisiana eco MSV 105 MT O 160-DLM End-face module
Length without sidewalls mm 937 1250 1875 2150 2500 3750 2150
Thickness of two sidewalls mm 60
Area of display part m2 1,8 2,3 3,5 4,0 4,7 7,0 4,0
Ambient temperature ˚С ≤ +25
Humidity % ≤ 60
Air velocity m/s ≤ 0,2
Operating temperature ˚С 0…+2 / +2…+4/ +4…+6
Temperature class М1/М2/Н1
Louisiana eco MSV 115 MT O 200-DLM End-face module* Louisiana eco NB MSV 115 MT O 200-DLM End-face module*
Length without sidewalls mm 950 1250 1875 2500 3750 2160* 950 1250 1875 2500 3750 2160*
Thickness of two sidewalls mm 70 70
Area of display part m2 2,8 3,6 5,4 7,3 10,9 6,3 2,8 3,6 5,4 7,3 10,9 6,3
Ambient temperature ˚С ≤ +25 ≤ +25
Humidity % ≤ 60 ≤ 60
Air velocity m/s ≤ 0,2 ≤ 0,2
Operating temperature ˚С 0…+2 / +2…+4/ +4…+6 0…+2 / +2…+4/ +4…+6
Temperature class М1/М2/Н1 М1/М2/Н1

* – it requires an additional agreement (marked in red)

The Manufacturer reserves the right to make alterations in the specifications.
